Chapter 03Fit · Know-how
How to measure a roofline for holiday lights from the ground
Stand under each corner of the gutter, mark the ground below it and tape from mark to mark: that is the eaves run. A gable needs two more numbers, its width at the eaves (taped on the ground) and its rise (count the siding rows from the eaves to the peak and multiply by one row). Each sloped edge is the square root of half the width squared plus the rise squared. A 24 ft gable that rises 6 ft has two 13.4 ft edges, 26.8 ft in all. Add 10% to the total.
Source: Christmas Light Emporium, rooflines and gables, checked October 9, 2026; Christmas Light Emporium planning guide, checked October 9, 2026.
- Every number on this page is taken from the ground0 ladders Christmas Light Emporium, rooflines and gables, October 9, 2026
- Both sloped edges of a 24 ft gable with a 6 ft rise26.8 ft Arithmetic from the figures on this page
- Slack on the total for corners and overlaps+10% Christmas Light Emporium planning guide, October 9, 2026
Sketch the front before you measure
Stand across the street with a pencil and draw the house as the neighbors see it. Mark each straight gutter run, each gable, any dormer and the corners where the roof turns. The Christmas Light Emporium's roofline planner says to write each section down on its own rather than as one total, because each run gets its own sets later.
Source: Christmas Light Emporium roofline planner, checked October 9, 2026.
- Straight eaves: every gutter edge you want lit, front first, then any side you see from the street.
- Gables: the triangle over a porch, a garage or the whole front.
- Dormers and returns: the short pieces that stick out. Each is its own small run.
- Where each run starts and ends, so you know which end the plug goes.
Tape the eaves on the ground
Find the gutter corners
Stand under one end of the gutter and look straight up. The downspout often sits at the corner and makes this easy.
Mark the ground
Put a stone, a stake or a chalk mark on the ground right below that corner. Do the same at the other end.
Tape mark to mark
Run the tape along the ground between the marks, with a helper holding the far end. Read it to the nearest half foot.
Write it on the sketch
Write the length next to that run. A run that turns a corner is two numbers, one per side.
Source: Christmas Light Emporium, rooflines and gables, checked October 9, 2026.
The Christmas Light Emporium describes measuring every roofline and gable edge from the ground, with a laser measure or by counting siding courses. A laser measure aimed along a wall works too, but a tape on the ground and a helper are enough.
Source: Christmas Light Emporium, rooflines and gables, checked October 9, 2026.
Work out each gable from its width and rise
The sloped edges of a gable are longer than the ground under them, so taping the footprint comes up short. The roofline planner tells you to measure every angled rake edge to the peak; you can do it from below with two numbers and the right-angle rule.
Source: Christmas Light Emporium roofline planner, checked October 9, 2026.
Tape the width
Mark the ground under both lower corners of the gable, where the sloped edge meets the gutter, and tape between them.
Count the siding rows
Count the rows of siding from the eaves line up to the peak. Measure one row at the bottom of the wall, where you can reach it.
Multiply for the rise
Rows times the height of one row is the rise. 18 rows of 4 inches is 72 inches, which is 6 ft.
Find the sloped edge
Halve the width, square it, add the rise squared, and take the square root. For a 24 ft gable with a 6 ft rise: 12 × 12 + 6 × 6 = 180, and the square root of 180 is 13.4 ft. Double it for both sides: 26.8 ft.
The rise is forgiving
Guess the rise of a 24 ft gable at 7 ft when it is really 6 ft and the two edges come out at 27.8 ft instead of 26.8 ft: one foot over. The 10% slack you add at the end covers a miss like that. The width is what to get right.
No siding rows? Two other ways to find the rise
- From a photo: stand straight across from the gable and take a photo. In the photo, measure the width and the rise with a ruler. The rise in feet is the real width times photo rise divided by photo width: 24 ft × 30 mm ÷ 120 mm is 6 ft.
- From the roof pitch: if old house papers or a roofing invoice give the pitch, such as 6 in 12, the rise is half the width times 6 ÷ 12. Half of 24 ft is 12 ft, and 12 × 6 ÷ 12 is 6 ft.
- Brick or stone instead of siding: count courses the same way and measure a few at the bottom of the wall, then divide to get one course.
Add it up and add 10%
Add every run on the sketch, then add 10% for corners, overlaps at downspouts and the turn at each end, which is the slack the Emporium's lights guide uses. The tool's worked example has 48 ft of straight eaves and that 24 ft gable: 48 + 26.8 = 74.8 ft, and 82.3 ft with slack. The roofline planner suggests 10 to 15%, so if your house has many short runs, round up rather than down.
Source: Christmas Light Emporium planning guide, checked October 9, 2026; Christmas Light Emporium roofline planner, checked October 9, 2026.
Measure from the ground, hire out the ladder work
This page covers the numbers only. Putting lights on a gutter or a roof edge means ladder work. If that isn't a job you do, a holiday light installer can hang them, and your measured sketch tells them exactly what you want.
Checklist to print
Work through it on a dry afternoon with a helper:
- Front of the house sketched from across the street
- Each run named on the sketch: eaves, gables, dormers
- Ground marked under every gutter corner
- Each straight eaves run taped mark to mark
- Each gable width taped at its lower corners
- One siding row measured and the rows to the peak counted
- Rise worked out for each gable
- Sloped edges worked out for each gable
- All runs added, plus 10%
- Numbers entered in the calculator and written on the lights plan sheet
Tips and tricks
- Tip 01
Measure in daylight, hang later
Leave the ground marks in place until the lights go up. They let you check a run against the sketch.
- Tip 02
Name the runs the same way everywhere
Use the same names on the sketch, the plan sheet and the tags on the sets: front eaves, porch gable, garage left. Next year the right set goes to the right run.
- Tip 03
Measure two matching gables once
If two peaks look the same from the street, tape both widths. If they match, enter one gable and set the count to two.
- Tip 04
Note the outlet on the sketch
Draw where each run will start and the nearest outdoor outlet, as the Emporium's guide suggests. That decides which end of the run the plug goes.
Source: Christmas Light Emporium, rooflines and gables, checked October 9, 2026.
What we would do
Tape the eaves, compute the gables, add 10%
Sketch the front from the street, mark the ground under each gutter corner and tape between the marks. For each gable, tape the width and count siding rows for the rise, then let the calculator do the sloped edges. Add 10%, buy the sets, and keep the sketch with the lights for next year.
Source: Christmas Light Emporium planning guide, checked October 9, 2026.
Questions
How do I measure my roofline for Christmas lights without a ladder?
Mark the ground below each gutter corner and tape between the marks for the eaves. For a gable, tape the width on the ground and count siding rows for the rise; the sloped edges follow from the right-angle rule.
Source: Christmas Light Emporium, rooflines and gables, checked October 9, 2026.
How long is the sloped edge of my roof peak?
Half the width squared plus the rise squared, then the square root. A 24 ft wide gable with a 6 ft rise has two 13.4 ft edges, 26.8 ft together.
Can I just measure the house along the ground?
For the straight eaves, yes. For a gable, no: the sloped edges are longer than the ground below them. A 24 ft gable with a 6 ft rise needs 26.8 ft of lights, not 24.
How much extra should I add to the roofline measurement?
Add 10% for corners, overlaps and the turn at each end. One retailer guide suggests 10 to 15%; with many short runs, lean toward the higher end.
Source: Christmas Light Emporium planning guide, checked October 9, 2026; Christmas Light Emporium roofline planner, checked October 9, 2026.
What if I guess the rise wrong?
It matters less than you might think. On a 24 ft gable, a 1 ft error in the rise changes both sloped edges together by about 1 ft, and the 10% slack absorbs that.
